Koyo T1F-08AD-1 8-Channel Analog Current Input Module, Industrial Control Automation
The Automation Direct T1F-08AD-1 is an advanced 8-channel analog current input module designed for industrial control systems. It efficiently converts analog current signals into 14-bit digital signals, making it ideal for use in various automation and control applications.
Module Type:Analog Current Input Module
Channels:Eight Single-Ended Channels
Input Ranges:-20 to 20 mA, 0 to 20 mA, 4 to 20 mA
Resolution:14-bit Digital Signal Conversion
Frequency Response:-3 dB at 500 Hz, -20 dB/decade
Operating Temperature Range:32°F to 131°F (0°C to 55°C)
Storage Temperature Range:-4°F to 158°F (-20°C to 70°C)
Compatibility:Terminator I/O Series, PLC Integration
The Koyo T1F-08AD-1 is a versatile eight-channel analog current input module designed for industrial automation systems. It efficiently converts analog current signals into digital signals, enabling precise monitoring and control of various processes. With three input ranges (-20 to 20 mA, 0 to 20 mA, and 4 to 20 mA), it provides flexibility for different applications. The module’s frequency response of -3 dB at 500 Hz ensures accurate signal processing within a wide range of frequencies. Designed for durability, the T1F-08AD-1 operates within a temperature range of 32℉ to 131℉ (0℃ to 55℃). Proper installation is crucial for optimal performance; it should be mounted horizontally to facilitate airflow and cooling. Refer to the user manual and datasheet for detailed installation and wiring instructions. With its robust design and reliable performance, the Koyo T1F-08AD-1 is an essential component for modern industrial automation systems.
