GE 531X300CCHANM3 Control Card for Industrial Drive Systems
The GE 531X300CCHANM3 Control Card is a high-quality replacement PCB designed for use in GE’s DC-300 drive systems. With its robust design and precise engineering, this control card ensures reliable operation in industrial environments.
Manufacturer:General Electric
Model Number:531X300CCHANM3
Alternate Board Number:F31X300CCHAFG1
Function:Control Card
Compatibility:DC-300 drive and similar drives
Board Markings:VA-4, FR00/0, CT 88-42
Potentiometers:Eight potentiometers
Connector Type:Stab-on connectors and single terminal-pin connectors
LED Indicators:Six red LED indicators
Transistors:Eleven transistors
Integrated Circuits:Dozens of integrated circuits including oscillating chips and operational amplifiers
Capacitors:Ceramic and polyester vinyl capacitors
Diodes:Multiple diodes
Resistors:Metal film resistors
The GE 531X300CCHANM3 is a critical component for controlling the operation of DC-300 drives and similar industrial systems. With its robust design, it ensures precise regulation and efficient operation in demanding industrial settings.
This Control Card comes equipped with eight potentiometers, allowing for fine-tuning of various parameters to meet specific application requirements. Additionally, the inclusion of a push button switch and jumper switches provides users with easy access to configuration options.
The board’s surface is populated with an array of electronic components, including eleven transistors and numerous integrated circuits. These components work together to provide reliable performance under a wide range of operating conditions.
The GE 531X300CCHANM3 is marked with essential codes and identifiers, such as VA-4, FR00/0, and CT 88-42, which can be used for identification and compatibility verification purposes. Its alternate board number, F31X300CCHAFG1, is also prominently displayed for quick reference.
Designed with durability in mind, this Control Card features ceramic or polyester vinyl capacitors, diodes, and metal film resistors, ensuring long-lasting performance even in challenging industrial environments.
