Allen Bradley 700-SH25GA24 Hockey Puck Solid State Relay
The A-B 700-SH25GA24 Hockey Puck Solid State Relay offers reliable and efficient switching capabilities for various industrial applications, including heating, lighting, and motor control systems. Its compact design and robust construction make it an ideal choice for demanding environments.
Input Voltage Range:10-30 VDC
Output Voltage Range:3-32 VDC, 25A @ 24VDC
Operating Temperature:-40°C to +85°C
Switching Time:<1ms
Isolation Voltage:3.75kVrms
Mounting Style:PCB Mount
Form Factor:Hockey Puck Design
Protection Features:Overload Protection, Short Circuit Protection
Certifications:CE, UL, RoHS Compliant
This A-B 700-SH25GA24 Hockey Puck Solid State Relay is a high-performance solution for industrial automation systems. It offers robust switching capabilities for loads up to 25A at 24VDC, making it suitable for demanding industrial environments. The relay features an optically isolated input signal, ensuring electrical isolation between the control circuit and load for enhanced safety and reliability. With its compact hockey puck design, this relay is easy to install and maintain, and can be mounted directly on a panel for space-efficient operation. The IP67 protection rating makes it resistant to dust and water ingress, ensuring long-lasting performance in harsh conditions. The relay is rated for operation from -25°C to +85°C, allowing for use in extreme temperature environments. Its high switching frequency of up to 10Hz allows for rapid response times, which is essential for fast-acting control systems. This relay is a vital component for any system requiring precise, reliable switching of electrical loads in a variety of applications.
