NI PXIE-5653 High-Speed Data Acquisition Module

NI PXIE-5653 High-Speed Data Acquisition Module

    The NI PXIE-5653 is a high-speed data acquisition module designed for precision measurements and rapid data logging in industrial automation environments. It enables real-time monitoring and analysis with its advanced signal processing capabilities.

Module Type:High-Speed Data Acquisition

Brand:National Instruments

Model:PXIE-5653

Sample Rate:Up to 5 MS/s

Resolution:16-bit

Channels:2

Input Range:-10 V to +10 V

Connector Type:BNC

Dimensions:4.2 x 2.9 x 0.9 inches

Weight:0.2 lbs

Compatibility:PCI Express x4 Gen 2

    The NI PXIe-5653 Digital Oscilloscope is designed for high-speed signal analysis in demanding applications.

     Its core feature is the ability to capture and analyze rapid transient signals with precision.

     With a sample rate of up to 2 GS/s and a bandwidth of 500 MHz across two channels, this oscilloscope provides deep insights into complex electronic systems.

     Equipped with advanced trigger modes including edge, pulse width, and window triggering, it ensures accurate signal detection under various conditions.

     Its robust design supports a wide input range of +/- 400 mV, and with a memory depth of 128 MSamples per channel, it captures detailed waveform data for thorough analysis.

     Ideal for aerospace, automotive, and communications testing, the PXIe-5653 integrates seamlessly into PXI Express systems, offering reliable performance in challenging environments.
