General Electric DS200TCTSG1AFE Simplex Trip Board
This GE DS200TCTSG1AFE Simplex Trip Board is an essential part of the Mark V Series designed for industrial control systems. It ensures the safety and reliability of critical processes through its advanced trip functionality.
Relays:12 plug-in relays
Connectors:3 16-pin connectors (JDR, JDS, JDT), 2 12-pin connectors (JN, JM)
Relay Identifiers:K1, K5, K12, etc.
Series:Mark V
Compatibility:Specifically tailored for GE Mark V series systems
Weight:Not specified in the document
Dimensions:Not specified in the document
This GE DS200TCTSG1AFE Simplex Trip Board is part of the Mark V Series products and is designed for Group 1 components. With its advanced design, it offers reliable performance in industrial control systems.
The board is equipped with 12 plug-in relays which provide enhanced functionality and durability. It also includes three 16-pin connectors (JDR, JDS, JDT) and two 12-pin connectors (JN, JM).
The identifiers for the relays start with the letter ‘K’ followed by a number, ensuring clear and easy identification during maintenance or installation processes.
This product is built to withstand harsh conditions and ensures smooth operation in critical industrial settings, making it an ideal choice for industrial automation projects.
Installation and integration of this board are straightforward, thanks to its user-friendly design and detailed documentation provided by General Electric.
