GE 745-W2-P5-G5-LO-A-L-R-E: Advanced Transformer Protection System
The GE 745-W2-P5-G5-LO-A-L-R-E is an advanced transformer protection system designed to manage and safeguard transformers, autotransformers, and reactors. Featuring adaptive technologies like Dynamic CT Ratio Mismatch Correction and Overexcitation Protection, this system ensures efficient operation and longevity.
Transformer Type:Suitable for transformers, autotransformers, and reactors
Display Size:40 characters
Keypad Features:Expanded keypad for manual setpoint entry
Protection Features:Dynamic CT Ratio Mismatch Correction, Overexcitation Protection, Transformer Overload Protection, Frequency Rate-of-Change Detection
Input Windings:Two windings per phase, three windings with 5 amps
Analog Inputs/Outputs:Available
Restricted Ground Fault:Yes
Mounting:Can be mounted on a standard 19” panel
The GE 745-W2-P5-G5-LO-A-L-R-E is designed to be an essential component in any transformer protection strategy.
Its advanced adaptive features enable real-time response to system events, ensuring optimal performance and longevity.
With an enhanced 40 character display and an expanded keypad, setting up and monitoring the system is made effortless.
The compact design, measuring 9 inches in height, 7 inches in width, and 7 ⅛ inches in depth, allows for easy installation on a standard 19-inch panel.
The unit provides critical insights through its LED indicators, alerting operators to various statuses and potential errors.
Built with reliability in mind, the system incorporates protection features like dynamic CT ratio mismatch correction, overexcitation protection, and more, ensuring that the transformers it safeguards are protected against unexpected faults.
