GE 369-HI-R-MM-0-0 Industrial Motor Management Relay – Streamlining Motor Protection and Management
This motor management relay from General Electric is specifically designed to provide advanced protection and monitoring for medium-sized motors. With built-in optional metering, it significantly reduces maintenance costs and downtime through efficient troubleshooting.
Control Power nominal:20 VA
Control Power maximum:65 VA
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:approx. 12 in H x 5 in W x 8 in L
Insulation Class:I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:approx. 4.5 kg
Input Frequency Range:20 to 100 Hz
RTD Inputs:Twelve 3-wire, 100Ω platinum, 100Ω nickel, 120Ω nickel, 10Ω copper
Differential Switch Time Delay:<200 ms
Operating Voltage Range:50-300 VDC / 40-265 VAC
The GE 369-HI-R-MM-0-0 is equipped with an optional metering feature and twelve RTD inputs, making it a versatile solution for safeguarding and controlling motors and accompanying motor equipment of medium size.
By leveraging waveform capture, event reports, data logging, and built-in optional metering capabilities, this model significantly reduces maintenance costs and time spent troubleshooting.
Its advanced metering technology and adaptive capabilities streamline the process of managing motor systems.
With a range of protection features including undervoltage auto-restart, reverse power, starter failure, kVA demand, kvar demand, kW demand, current demand, backspin detection, self test/service, trip counter, and more, this relay ensures reliable operation under various conditions.
Crafted with precision, the 369-HI-R-MM-0-0 is built to withstand industrial environments with its robust insulation class and accurate phase current input conversion.
Ideal for industrial applications requiring precise motor management and protection.
