B&R Hybrid Module 7CM2117 – 2003 Combination Module for Industrial Automation
The B&R Hybrid Module 7CM2117 is a versatile combination module designed for industrial control systems. It integrates both input and output functionalities including 8 digital inputs, 2 incremental encoders, and 8 transistor outputs. Ideal for applications requiring precise counting and encoding functions.
Input Channels:8 channels, 24 VDC, 4 ms response time, sink type
Counter Channels:3 one-channel or 2 two-channel counters, or 2 incremental encoders, up to 20 kHz
Output Channels:8 transistor outputs, 24 VDC, 0.5 A per channel
Comparator Function:Yes
Short Circuit Protection:Yes
Analog Inputs:2 channels, ±10 V / 0 to 20 mA, 12-bit resolution
Analog Outputs:2 channels, ±10 V, 12-bit resolution
Terminal Blocks:Order 2x TB718 terminal blocks separately
The B&R Hybrid Module 7CM2117 represents an innovative solution for industrial automation systems. It integrates eight digital input channels with high-speed response and sink-type connections, making it suitable for a wide range of industrial processes. Additionally, it features robust counting and encoder interfaces, supporting up to three single-channel or two dual-channel counters, or two incremental encoders operating at up to 20 kHz. Eight transistor outputs provide reliable switching capabilities, each capable of handling up to 0.5 A. Enhanced with a built-in comparator function and short-circuit protection, this module ensures efficient and secure operation. Its analog inputs and outputs, with ±10 V and 0 to 20 mA ranges, deliver precise control over analog signals. For convenient installation, this module is designed to be used with separate TB718 terminal blocks (sold separately). Crafted with high-quality materials and precision engineering, the B&R Hybrid Module 7CM2117 is a dependable choice for any industrial environment, enhancing productivity and efficiency.
