B&R 7CM2117 Digital Input Module – Industrial Automation Control
The B&R 7CM2117 Digital Input Module is designed for industrial automation applications, providing reliable and efficient signal conversion from digital to programmable logic controller (PLC) systems. It supports up to 8 digital inputs, making it ideal for use in manufacturing, process control, and robotics.
Module Type:Digital Input Module
Inputs:8 x 24 VDC, 4 ms response time, sink type
Counter Capability:3 one-channel or 2 two-channel counters, or 2 incremental encoders up to 20 kHz
Outputs:8 transistor outputs, 24 VDC, 0.5 A each
Protection Features:Short circuit protection, comparator function
Analog Inputs:2 x ±10 V / 0 to 20 mA, 12-bit resolution
Analog Outputs:2 x ±10 V, 12-bit resolution
Order Accessories:TB718 Terminal Blocks (sold separately)
The B&R 7CM2117 Digital Input Module is engineered to meet the demands of modern industrial environments. Designed with a robust build, this module offers superior performance in signal acquisition and processing. Its compatibility with various input types allows seamless integration into existing systems, enhancing overall efficiency and accuracy. Each input channel supports up to 4 ms response times, ensuring quick and reliable data capture. The inclusion of counter and encoder functions provides additional flexibility, supporting both single and dual-channel configurations. For output management, the module delivers stable 24 VDC, 0.5 A currents across 8 channels, complete with short circuit protection to safeguard system integrity. The module’s built-in comparator function further enhances its utility in precision control applications. Furthermore, the provision for ±10 V and 0 to 20 mA analog inputs/outputs ensures adaptability to a wide array of industrial sensors and actuators. The ordering of 2x TB718 terminal blocks is necessary for setup, allowing for easy installation and maintenance. Overall, the B&R 7CM2117 is a versatile and dependable choice for industrial automation projects seeking advanced digital input capabilities.
