Allen-Bradley 46713PCB Hall Effect, LFB, Trapezoidal Module

Allen-Bradley 46713PCB Hall Effect, LFB, Trapezoidal Module

    The ABB 46713PCB is a high-performance Hall Effect sensor designed for Linear Feedback (LFB) trapezoidal drives. It provides precise control and monitoring capabilities, making it ideal for industrial automation systems requiring robust and reliable performance.

Manufacturer:Rockwell Automation

Model Number:46713PCB

Type:Hall Effect PCB

Control Method:LFB Trapezoidal

Compatibility:Suitable for various industrial motors

Dimensions:Approximately 4.5 inches x 4.5 inches

Voltage Range:12V to 24V DC

Operating Temperature:-40°C to +85°C

Storage Temperature:-55°C to +125°C

Certifications:CE, RoHS Compliant

    The A-B 46713PCB Hall Effect module is an essential component for any advanced industrial control system. With its Hall Effect technology, it provides highly accurate linear feedback, ensuring smooth operation and high precision in motion control applications. This module is capable of generating trapezoidal waveforms, which are ideal for driving brushless motors and other similar applications. Its robust design includes a compact form factor that fits seamlessly into existing systems. The module is built to withstand harsh industrial environments, operating within a wide temperature range from -20°C to +85°C, making it suitable for use in various settings. It is certified to meet CE and RoHS standards, ensuring compliance with international regulations. Installation is straightforward, and the module comes with detailed instructions to guide you through the process.
